- XMK Claw knife type crusher series wide applicability, mainly used for crushing all kinds of soft and hard plastic, different types of plastic broken into granular, and then recycling;
- The model machine with stainless steel, compact structure, safe and durable;
- Special claws blade rotor design, making the machine easier when broken material easily;
- Tool using SKD-11 material production, and the knife after the tool is designed telescopic adjustment, with a blunt blade can grind the blade, durable;
- Body cooling water system installation, remove the heat generated by the machine at work, avoid crushed material agglomeration;
- The whole human design, opening and closing the feed hopper, removable mesh tool and replacement easy.

Unique tool design
Machine tool with high strength SKD-11 material, stepped rotor design, the machine in the cutting increased torque, smash the particles more uniform.

Electrical parts
Using Siemens appliances, star delta start mode, to ensure the safety of the use of the machine.

Motor installation
External motor through the U-slot in the fixed, easy to adjust the belt tightness.

Model		XMK-15C	XMK-20C	XMK-30C
Fixed blade knife		2*2	2*2	2*2
Rotating knife		3*7	3*8	3*11
Grinding chamber diameter	mm	420*270*Φ300	480*340*Φ350	660*400*Φ380
Power	kw	11KW/15HP	15KW/20HP	22KW/30HP
Rotating speed		540	540	540
Crushing ability	mm	300-500	350-550	500-800
Sieve aperture	mm	Φ8	Φ10	Φ10
Weight	kg	800	1200	1500
Dimensions	L*W*H mm	1320*900*1540	1560*960*1850	1700*1200*1900

We reserve right to change specifications without prior notice.
